TECHNICAL DETAILS:

Slab Thickness         Total Load including                     Permissible Clear spans for centre line spacing

                                        180 Kg/Sq.m

                                  for shuttering and live load

mm                                                                                     600              800            900          1150

                                                                                           mm              mm           mm          mm

125                                       480                                        5330           4650          4340         3760

150                                       540                                        5000           4350          4090         3560

200                                       660                                        4520           3950          3680         3200

250                                       780                                        4140           3650          3380         2840

300                                       900                                        3730           3400          3150         2400

                             Min.                       Max.

ESO+ESI             175cm                   270cm

SO+ESI               240cm                   345cm

SO+SI                 245cm                    412cm

SO+LI                 305cm                    475cm

LO+SI                 315cm                    485cm

LO+LI                 315cm                    550cm

Load tables for various slab thickness and spans. Overall length of span= Clear span + 13 cm
